توضیحات
| نوع محصول | توان نامی استاندارد موتورهای سه فاز 50/60Hz کلاس AC-3 | تنظیم محدوده جریانی (A) | |||||
| 220V | 380V | 415V | 440V | 500V | 660V | ||
| KW | KW | KW | KW | KW | KW | ||
| ET9-V1-MO1 | – | – | – | – | – | – | 0.1-0.16 |
| ET9-V1-MO2 | – | – | – | – | – | – | 0.16-0.25 |
| ET9-V1-MO3 | – | – | – | – | – | – | 0.25-0.4 |
| ET9-V1-MO4 | – | – | – | – | – | 0.37 | 0.4-0.63 |
| ET9-V1-MO5 | – | – | – | 0.37 | 0.37 | 0.55 | 0.63-1 |
| ET9-V1-MO6 | – | 0.37 | – | 0.55 | 0.75 | 1 | 1-1.6 |
| ET9-V1-MO7 | 0.37 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| ET9-V1-MO8 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| ET9-V1-M10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4.0 – 6.0 |
| ET9-V1-M14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6.0 – 10 |
| ET9-V1-M20 | 4 | 7.5 | 7.5 | 7.5 | 10 | 11 | 10.0 – 16 |
| ET9-V1-M21 | 5.5 | 10 | 9 | 9 | 11 | 15 | 16 – 20 |
| ET9-V1-M22 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 20 – 25 |
| ET9-V2-MO1 | – | – | – | – | – | – | 0.1 – 0.16 |
| ET9-V2-MO2 | – | – | – | – | – | – | 0.16-0.25 |
| ET9-V2-MO3 | – | – | – | – | – | – | 0.25-0.4 |
| ET9-V2-MO4 | – | – | – | – | – | 0.37 | 0.4-0.63 |
| ET9-V2-MO5 | – | – | – | 0.37 | 0.37 | 0.55 | 0.63-1 |
| ET9-V2-MO6 | – | 0.37 | – | 0.55 | 0.75 | 1 | 1-1.6 |
| ET9-V2-MO7 | 0.37 | 0.75 | 0.75 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| ET9-V2-MO8 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| ET9-V2-M10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4.0 – 6.0 |
| ET9-V2-M14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6.0 – 10 |
| ET9-V2-M16 | 3 | 5.5 | 5.5 | 7.5 | 7.5 | 9 | 9.0 – 14 |
| ET9-V2-M20 | 4 | 7.5 | 9 | 9 | 9 | 11 | 13-18 |
| ET9-V2-M21 | 5.5 | 11 | 11 | 11 | 11 | 15 | 17-23 |
| ET9-V2-M22 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 20-25 |
| ET9-V2-M32 | 7.5 | 15 | 15 | 15 | 18.5 | 26 | 24-32 |
| ET9-V3-MO6 | – | 0.37 | – | 0.55 | 0.75 | 1.1 | 1-1.6 |
| ET9-V3-MO7 | 0.37 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| ET9-V3-MO8 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| ET9-V3-M10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4-6.3 |
| ET9-V3-M14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6.0-10 |
| ET9-V3-M20 | 4 | 7.5 | 7.5 | 7.5 | 10 | 11 | 10.0 – 16 |
| ET9-V3-M25 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 16-25 |
| ET9-V3-M40 | 11 | 18.5 | 22 | 22 | 25 | 33 | 25-40 |
| ET9-V3-M63 | 15 | 30 | 33 | 33 | 40 | 55 | 40-63 |
| ET9-V3-M80 | 22 | 40 | 45 | 45 | 55 | 63 | 56-80 |
